HUAWEI M-Pencil Silver 2nd Generation - (PENCIL)

Integrated design

Metallic silver

160 mm x φ8.9 mm (max), width: 8.7 mm (min)

Note: The actual dimensions may vary depending on the configurations, manufacturing processes, and measurement methods.

About 16 g (including the battery)

Note: The actual weight may vary based on the configurations, manufacturing processes, and measurement methods

l Touch button (can be double-tapped in some apps to switch features)

Bluetooth 5.1

Bluetooth range: 2402–2480 MHz, 13 dB

Bluetooth pairing: Attached magnetically and paired automatically

Pairing for the first time: Touch the pairing icon in the pairing pop-up window.

Not supported

Charged by a wireless charger

Cannot charge other devices

Capacity: 82 mAh, lithium polymer battery

Charging time: Less than 1 hour

Note: The above data comes from Huawei lab tests during which the tablet was charged by a standard charger with its screen turned off. The actual charging time may vary.

Input: 5V-300 mA

Note: A Huawei tablet or a C-CD52-Adapter is required.

HPP protocol

Acceleration sensor

Voltameter

Pressure sensor

Operating temperature: 0°C to 35°C

Storage temperature: –20°C to +45°C

5% to 95%

Water resistance during daily use

RoHS certification (China), SRRC certification, and BT certification

CE (pan-European), RoHS (pan-European), REACH (pan-European), WEEE (pan-European),

KC (South Korea), Telec (Japan), IC (Canada)

l Not supported

l Not supported

l Not supported

l Not supported

Wagner table and MatePad Pro. (supports magnetic charging)

MatePad 10.8". (Does not support magnetic charging, use a C-CD52-Adapter instead.)
