KD129.90
Bar-type
• Type: OLED, up to 120 Hz frame refresh rate, 300 Hz touch sampling rate
• Color: 1.07 billion colors, Color gamut (P3)
• Resolution: 2340 x 1080 pixels; 392 PPI
Multi-touch, supporting a maximum of 10 touch points
• Starry Blue
• Black
160 mm (H) x 73.7 mm (W) x 7.77 mm (D)
Note: The actual dimensions may vary depending on the configuration, manufacturing process, and measurement method.
Approx. 175g (including the battery)
Note: The actual weight may vary depending on the configuration, manufacturing process, and measurement method.
Li-ion Polymer Battery
• 4G LTE FDD:
• FDD-LTE B1: 1920 - 1980 MHz(UL), 2110 - 2170 MHz(DL)
• FDD-LTE B2: 1850 - 1910MHz(UL), 1930 - 1990MHz(DL)
• FDD-LTE B3: 1710 - 1785 MHz(UL), 1805 - 1880 MHz(DL)
• FDD-LTE B4: 1710 - 1755MHz(UL), 2110 - 2155MHz(DL)
• FDD-LTE B5: 824 - 849MHz(UL), 869 - 894MHz(DL)
• FDD-LTE B7: 2500 - 2570MHz(UL), 2620 - 2690MHz(DL)
• FDD-LTE B8: 880 - 915MHz(UL), 925 - 960MHz(DL)
• FDD-LTE B12: 699-716 MHz(UL), 729 -746MHz(DL)
• FDD-LTE B17: 704-716MHz(UL), 734 -746MHz(DL)
• FDD-LTE B18: 815 - 830MHz(UL), 860 - 875MHz(DL)
• FDD-LTE B19: 830 - 845MHz (UL), 875 - 890MHz(DL)
• FDD-LTE B20: 832 - 862MHz(UL), 791 - 821MHz(DL)
• FDD-LTE B26: 814 - 849MHz(UL), 859 - 894MHz(DL)
• FDD-LTE B28: 703 - 748MHz(UL), 758 – 803MHz(DL)
• FDD-LTE B66: 1710-1780 MHz(UL),2110-2200 MHz(DL，2180-2200MHz only for CA）DL)
• 4G LTE TDD:
• TD-LTE B34: 2010 - 2025 MHz
• TD-LTE B38: 2570 - 2620 MHz
• TD-LTE B39: 1880 - 1920 MHz
• TD-LTE B40: 2300 - 2400 MHz
• TD-LTE B41: 2496 - 2690 MHz
• 3G WCDMA:
• WCDMA B1: 1920 - 1980 MHz(UL), 2110 - 2170 MHz(DL)
• WCDMA B2: 1850 - 1910 MHz(UL), 1930 - 1990 MHz(DL)
• WCDMA B4: 1710 - 1755 MHz(UL), 2110 - 2155 MHz(DL)
• WCDMA B5: 824 - 849 MHz(UL), 869 - 894 MHz(DL)
• WCDMA B6: 830 - 840MHz(UL), 875 - 885MHz(DL)
• WCDMA B8: 880 - 915 MHz(UL), 925 - 960 MHz(DL)
• WCDMA B19: 830 - 845MHz(UL), 875 - 890MHz(DL)
• 2G GSM:
• GSM B2: 1850 - 1910 MHz(UL), 1930 - 1990 MHz(DL)
• GSM B3: 1710 - 1785 MHz(UL), 1805 - 1880 MHz(DL)
• GSM B5: 824 - 849 MHz(UL), 869 - 894 MHz(DL)
• GSM B8: 880 - 915 MHz(UL), 925 - 960 MHz(DL)
• Note:
• * Either card slot can be set to accommodate the primary or secondary SIM card.
• * Confirm whether the dual-SIM 4G network are supported based on the situations of carrier's network and related services deployment. The subsequent software feature of the phone may update with the matching network. The supported feature is subject to the actual version of the phone.
• * Functions available on the live network depend on the carrier network.
• 4G LTE FDD:
• FDD-LTE B1: 21 - 25 dBm(Power Class 3)
• FDD-LTE B2: 21 - 25 dBm(Power Class 3)
• FDD-LTE B3: 21 - 25 dBm(Power Class 3)
• FDD-LTE B4: 21 - 25 dBm(Power Class 3)
• FDD-LTE B5: 21 - 25 dBm(Power Class 3)
• FDD-LTE B7: 21 - 25 dBm(Power Class 3)
• FDD-LTE B8: 21 - 25 dBm(Power Class 3)
• FDD-LTE B12: 21 - 25 dBm(Power Class 3)
• FDD-LTE B17: 21 - 25 dBm(Power Class 3)
• FDD-LTE B18: 21 - 25 dBm(Power Class 3)
• FDD-LTE B19: 21 - 25 dBm(Power Class 3)
• FDD-LTE B20: 21 - 25 dBm(Power Class 3)
• FDD-LTE B26: 21 - 25 dBm(Power Class 3)
• FDD-LTE B28: 21 - 25 dBm (Power Class 3)
• FDD-LTE B66: 21 - 25 dBm (Power Class 3)
• 4G LTE TDD:
• TD-LTE B34: 21 - 25 dBm(Power Class 3)
• TD-LTE B38: 21 - 25 dBm(Power Class 3)
• TD-LTE B39: 21 - 25 dBm(Power Class 3)
• TD-LTE B40: 21 - 25 dBm(Power Class 3)
• TD-LTE B41: 21 - 25 dBm(Power Class 3)
• 3G WCDMA:
• WCDMA B1: 21 - 25 dBm(Power Class 3)
• WCDMA B2: 21 - 25 dBm(Power Class 3)
• WCDMA B4: 21 - 25 dBm(Power Class 3)
• WCDMA B5: 21 - 25 dBm(Power Class 3)
• WCDMA B6: 21 - 25 dBm(Power Class 3)
• WCDMA B8: 21 - 25 dBm(Power Class 3)
• WCDMA B19: 21 - 25 dBm(Power Class 3)
• 2G GSM:
• GSM B2: 28 - 32 dBm(Power Class 1)
• GSM B3: 28 - 32 dBm(Power Class 1)
• GSM B5: 31 - 35 dBm(Power Class 4)
• GSM B8: 31 - 35 dBm(Power Class 4)
• 4G FDD-LTE:
• FDD-LTE B1: better than - 96.3 dBm/10 MHz
• FDD-LTE B2: better than - 94.3 dBm/10 MHz
• FDD-LTE B3: better than - 93.3 dBm/10 MHz
• FDD-LTE B4: better than - 96.3 dBm/10 MHz
• FDD-LTE B5: better than - 94.3 dBm/10 MHz
• FDD-LTE B7: better than - 94.3 dBm/10 MHz
• FDD-LTE B8: better than - 93.3 dBm/10 MHz
• FDD-LTE B12: better than - 94.3 dBm/10 MHz
• FDD-LTE B17: better than - 94.3 dBm/10 MHz
• FDD-LTE B18: better than - 96.3 dBm/10 MHz
• FDD-LTE B19: better than - 96.3 dBm/10 MHz
• FDD-LTE B20: better than - 93.3 dBm/10 MHz
• FDD-LTE B26: better than - 93.8 dBm/10 MHz
• FDD-LTE B28: better than -94.8dBm/10MHz
• FDD-LTE B66: better than - 96.3 dBm/10 MHz
• 4G TD-LTE:
• TD-LTE B34: better than - 96.3 dBm/10 MHz
• TD-LTE B38: better than - 96.3 dBm/10 MHz
• TD-LTE B39: better than - 96.3 dBm/10 MHz
• TD-LTE B40: better than - 96.3 dBm/10 MHz
• TD-LTE B41: better than - 94.3 dBm/10 MHz
• 3G WCDMA:
• WCDMA B1: better than - 106.7 dBm/3.84 MHz
• WCDMA B2: better than - 104.7 dBm/3.84 MHz
• WCDMA B4: better than - 106.7 dBm/3.84 MHz
• WCDMA B5: better than - 104.7 dBm/3.84 MHz
• WCDMA B6: better than - 104.7dBm/3.84MHz
• WCDMA B19: better than - 106.7dBm/3.84MHz
• 2G GSM:
• GSM(GSM 850): 824MHz - 849MHz(UL), 869MHz - 894MHz(DL)
• EGSM(GSM 900): 880MHz - 915MHz(UL), 925MHz - 960MHz(DL)
• DCS(GSM 1800): 1710MHz - 1785MHz(UL), 1805MHz - 1880MHz(DL)
• PCS(GSM 1900): 1850MHz - 1910MHz(UL), 1930MHz - 1990MHz(DL)
• GSM B2: better than - 102 dBm/200 kHz
• GSM B3: better than - 102 dBm/200 kHz
• GSM B5: better than - 102 dBm/200 kHz
• GSM B8: better than - 102 dBm/200 kHz
Refer to " Nottingham CA list"
• DL 4*4 MIMO: Support B1,B3, B38, B41
• UL 2*2 MIMO: Not supported
UL: 64 QAM
• DL: 256 QAM
TD-LTE/FDD-LTE/WCDMA/HSPA+/DC-HSDPA/EVDO/ EDGE/GPRS
Support VoLTE/ViLTE
Note:
Functions available on the live network depend on the carrier network.
Dual SIM card version:
• Card slot 1: nano-SIM card
• Card slot 2: nano-SIM card
Single SIM card model:
• Card slot 1: nano-SIM card
• Card slot 2: NA
Dual SIM model:
Support dual SIM dual standby
One Nano SIM + One Nano SIM
*In Dual SIM version, either card slot can be set to accommodate the primary or secondary SIM card.
*Functions available on the live network depend on the situations of carrier's network and related services deployment.
Single SIM model:
One Nano SIM
*Functions available on the live network depend on the situations of carrier's network and related services deployment.
Qualcomm Snapdragon™ 778G 4G
Standard USB Type-C
8 GB RAM + 128 GB ROM
Not supported.
• Physical Power key
• Physical Volume key
GPS (L1 + L5 Dual band) / AGPS / GLONASS/ BeiDou(B1I+B1C+B2a
Tri-band) / GALILEO (E1 + E5a Dual band) / QZSS (L1 + L5 Dual band) / NavIC
• Operating temperature: 0℃ - 35℃
• Warehouse temperature: -20℃ - +45℃
• Capability: 4300 mAh (typical value), 4200 mAh (rated value)
• Theoretical Charging Time: About 0.63 hours from supplied charger
Note: Laboratory data is generated by charging the phone using the standard charger with the screen off. The actual charging time may vary depending on usage.
The data is derived from laboratory testing. The actual standby time, talking time, video play, music play, 4G Internet access, and dual card standby time depend on the user operation, network condition.
• WCDMA network: up to523.5 hours standby time; up to27 hours talking time.
• GSM network: up to 521.7 hours standby time; up to 40.1 hours talking time.
• LTE TDD network: up to 534.7 hours standby time.
• LTE FDD network: up to 533.3 hours standby time.
• Video play: up to 21.6 hours.
• Music play: up to55.4hours.
• 4G Internet access: up to15.1hours.
Working: 5% - 95%
• Rear camera: 50 MP High-Resolution Camera (f/1.9 aperture) + 8MP Ultra Wide Angle Camera (f/2.2 aperture) + 2 MP Depth Camera (f/2.4 aperture) + 2 MP Macro Camera (f/2.4 aperture)
• Front camera: 32 MP Portrait Camera (f/2.0)
Note: The photo pixels may vary depending on the shooting mode.
Bluetooth 5.2, Support BLE, SBC, AAC, LDAC
802.11a/b/g/n/ac/ax, 2x2 MIMO, HE160, 4096 QAM, 8 Spatial-stream Sounding MU-MIMO( Notes: Need router support.)
Download and upload peak physical rate up to 2.88 Gbps( Notes: Based on the 160MHz bandwidth Wi-Fi 6 router.)
Support 2.4GHz and 5GHz
Support Wi-Fi direct (Note: Connected devices must also support Wi-Fi Direct)
USB Type-C, USB 2.0
• Input: 100-240V~50/60Hz, 1.8A
• Output: 5V/2A,10V/4A,11V/6AMAX
Not supported.
CE, Wi-Fi, RoHS, REACH, WEEE,ERP,BQB, GCF
• Fingerprint sensor (UD)
• Proximity sensor
• Ambient light sensor
• compass
• Gravity sensor
• Gyroscope
Read Write mode/Peer to Peer mode/Card Emulation mode (payment by *SIM card, or HCE) is supported.
*The SIM card used for SIM card payment can only be inserted into the SIM1 card slot.
LED
EMUI 12.0 (Based on Android 11)
Celia Keyboard
EMUI 12.0
Supported
• VoLTE: AMR-WB/AMR-NB
• WCDMA: AMR-WB
• GSM: FR/EFR/HR/FR AMR/HR AMR
• SMS
• MMS
POP3/IMAP/Exchange
File format:
• Audio file format: *.mp3, *.mp4, *.3gp, *.ogg, *.amr, *.aac, *.flac, *.wav, *.midi
• Video file format: *.3gp, *.mp4
• Image file format: *.png, *.gif, *.jpg, *.bmp, *.webp, *.wbmp
File format: *.mp4, *.3gp
HOTA online update
• USB tethering
• Charging
• OTG
• MTP
• Headset
Rear camera:Support for 4K(3840 x 2160) 60fps video recording
Front camera:Support for 4K(3840 x 2160) 60fps video recording
• Capture file format: *.jpg
• Recording file format: *.mp4
Support digital compass based on Android
Wi-Fi Hotspot, Wi-Fi Direct, Bluetooth, USB Type- C
